Brand:
BI Technologies
| Mounting | SM |
|---|---|
| Shape | EE |
| Length | 8.1mm |
| Width | 7.2mm |
| Height | 5.3mm |
| Inductance Type | - |
| Packaging Options | Tape & Reel |
| RoHS Compliant | Yes |
| Inductance Min | 180uH |
|---|---|
| Inductance Max | 3000uH |
| Rated Current @ 25°C ambient Min | - |
| Rated Current @ 25°C ambient Max | 20A |
| Saturation Current @ 25°C ambient Min | - |
| Saturation Current @ 25°C ambient Max | - |
| DC Resistance Min | 1Ω |
| DC Resistance Max | 7.36Ω |
| Operating Temperature Min | -40°C |
| Operating Temperature Max | 130°C |
| Application | Current sense |
| AEC-Q200 Certified | False |
|---|
