PEAD36BF-13-2-B2
Desktop Power Supply 19V 30 Watt
Lifecycle:
Mature
Series:
PEAD36B
Class I and Class II Versions
Level VI Efficiency
CoC Tier 2**
Optional LED on Indicator
<100mW No Load Power Consumption
Overload Protection
Short Circuit Protection
RoHS Compliant
Specifications
| Output Power | 30W |
|---|---|
| Output Voltage 1 | 19V |
| Output Voltage 2 | - |
| Output Voltage 3 | - |
| Output Current | 1.58A |
| Output Current 2 | - |
| Output Current 3 | - |
| Input Connector | C18 |
| Output Connector | 2.5mm |
| Class |
|
| Temperature | 0-60C |
| Dimensions | 45x100x31mm |
