PAA10-10

Encapsulated Power Supply 5V 10 Watt

Lifecycle:

Mature

Brand:

Power Partners

Series:

PAA10

Quote Request
Data Sheet
checkmark

Ultra Compact Size 1.46” x 1.08”

checkmark

Universal Input Range 90-305VAC, 47-440Hz

checkmark

I/O Isolation 4000VAC

checkmark

Operating Ambient Temperature Range –40°C to +70°C

checkmark

No Load Power Consumption < 0.1W

checkmark

High Efficiency up to 86%

checkmark

EMC Compliant without External Components

checkmark

Safety Approval to UL/IEC/EN 62368-1, IEC/EN 60950, TUV IEC/EN60335-1, and TUV IEC/EN 61558-2-16

checkmark

Specifications

Output Power 10W
Output Voltage 5V
Output Current 2A
Class II
Temperature -40°C to 70°C (Linear decline from 100% @50 to 50% @70)C
Dimensions 27.5x37x23.5mm
Product Brand Power Partners
