PAAM15-10C
Encapsulated Power Supply 5V 15 Watt, Chassis Mount
Lifecycle:
Mature
Brand:
Power Partners
Series:
PAAM15
PCB Mountable Switching Power Supply
Fully Encapsulated Plastic Case
Universal Input Range (90-264VAC)
Regulated Output and Low Ripple and Noise
<0.1W No Load Input Power
Isolation Class II
Small Size
CE, CB, UL, cUL Approvals
Specifications
| Output Power | 15W |
|---|---|
| Output Voltage | 5V |
| Output Current | 3A |
| Class | II |
| Temperature | -40-80 (linear increase from 80% @-40 to 100% @-30, and linear decrease from 100% @55 to 30% @80)C |
| Dimensions | 27.94x53.34x22.86mm |
| Product Brand | Power Partners |
