PAAM150-14
Encapsulated Power Supply 24V 150 Watt
Lifecycle:
Mature
Brand:
Power Partners
Series:
PAAM150
PCB Mountable Switching Power Supply
4000VAC Input to Output 2MOPP Insulation
Cooling by Free Air Convection
High Efficiency up to 93.5%
Active P.F.C. Power Factor >0.9
<0.5W No Load Input Power
±5% Adjustable Voltage
EMI for Both Class I (with PE) and Class II (without PE) Configurations
Suitable for BF Applications with Appropriate System Consideration
Remote ON/OFF Function
Specifications
| Output Power | 150W |
|---|---|
| Output Voltage | 24V |
| Output Current | 6.25A |
| Class |
|
| Temperature | -30-70 (linear increase from 80% @-30 to 100% @-20, and linear decrease from 100% @50 to 50% @70)C |
| Dimensions | 109x58.5x36mm |
| Product Brand | Power Partners |
