PM301-18C
Enclosed Power Supply 48V 300 Watt
Lifecycle:
Mature
Brand:
Protek
Series:
PM301
BF Class insulation
Operation altitude up to 5000 meters
Suitable for both Class I and Class II applications*
3 x 6 inch foot print with 1.5 inch low profile
Less than 220 μA leakage current
Meet EN55011/55022 and FCC Class B
Power Factor 0.98 typical
100% burn-in at full load
Short-circuit protection (Latch)
Power Fail Detect (PFD) signal
Inhibit - TTL high to disable output
Compliant with RoHS requirements
High Efficiency 92% typical
Power consumption in standby mode less than 1W at standby power 5 V/100 mA
Specifications
| Output Power | 300W |
|---|---|
| Number of Outputs | 1V |
| Output Voltage 1 | 48V |
| Output Voltage 2 | - |
| Output Voltage 3 | - |
| Output Voltage 4 | - |
| Output Current 1 | 4.17A |
| Output 1 Max Current with CFM | 6.25A |
| CFM | 10A |
| Output 2 Max Current | - |
| Output 3 Max Current | - |
| Output 4 Max Current | - |
| Application | Medical |
| Class |
|
| Battery Charger | False |
| Temperature | 0-70 (Derate from 100% at +50℃ linearly to 50% at +70℃, applicable to convection and forced-air cooling conditions)C |
| Dimensions | 76.2x152.4x35.1mm |
| Product Brand | Protek |
