| Series | Zerohm |
|---|---|
| Application | Zero ohm jumper |
| Mounting | Through hole |
| Package | Axial |
| Technology | Thick film |
| Approval | DSCC |
| Example MPN | RG1/4ZEROHMLF |
| Termination Options | - |
| Power | - |
|---|---|
| Rated Ambient Temperature | - |
| De-rate to 0W Ambient Temperature | - |
| Max Ambient Temperature | 150°C |
| LEV | - |
| Resistance min | 0Ω |
| Resistance max | 0.01Ω |
| Critical Resistance (where applying LEV dissipates Pr) | - |
| Best Tolerance | - |
| Best TCR | - |
| Isolation Voltage of Insulation | 500V |
| RoHS Compliant (if Pb-free) | - |
|---|---|
| RoHS Exemption | - |
| China RoHS (if Pb-free) | - |
| REACH Status (if Pb-free) | - |
| CMRT Conflict Mineral Status | - |
| EMRT Extended Mineral Status | - |
| Termination Finish (if Pb-free) | e3 - Sn matt plated |
| Termination Finish (if Pb-bearing) | 60/40 |
| How to Specify Pb-Free | European PN has no PB suffix, USA PN has LF suffix |
| ECCN | - |
| Packing | Tape & reel |
|---|---|
| Quantity | 1250 |
| Nett Weight Each | - |
| Reflow Process | Not applicable |
| MSL | Not applicable |
| Wave Process | Compatible, 260+-5 deg. C, 1 or 2 x 5+-1 seconds contact time |
| Shelf-life | None defined, but solderability test prior to use is recommended after two years from date of manufacture |
| Launch Date | Pre-2000 |
|---|---|
| Lifecycle | Obsolete |
| EOL Date / YTEOL Estimate | EOL in 2014 |
| Latest PCN Date | 19 Sep 14 |
| Alternative Part Number | WL4 |
| Datasheet | ZEROHM | |
| Application Note | TN001 Advice on Storage Conditions for Fixed Resistors | |
| Application Note | TN007 Instant Access to Life Cycle and Obsolete Product Data Online | |
| Product Change Notification | PCNs for ZEROHM |
