Lifecycle:
Obsolete
Brand:
IRC
Series:
TPD
| Series | TPD |
|---|---|
| Application | Fusible |
| Mounting | Through hole |
| Package | Radial |
| Technology | Metal element |
| Approval | None |
| Example MPN | TPD-235C-55A |
| Termination Options | Pb-free |
| Power | - |
|---|---|
| Rated Ambient Temperature | 135°C |
| De-rate to 0W Ambient Temperature | 170°C |
| Max Ambient Temperature | 175°C |
| LEV | - |
| Resistance min | 0Ω |
| Resistance max | .7mΩ |
| Critical Resistance (where applying LEV dissipates Pr) | - |
| Best Tolerance | - |
| Best TCR | - |
| Isolation Voltage of Insulation | Unspecified: ?V |
| RoHS Compliant (if Pb-free) | - |
|---|---|
| RoHS Exemption | - |
| China RoHS (if Pb-free) | - |
| REACH Status (if Pb-free) | - |
| CMRT Conflict Mineral Status | - |
| EMRT Extended Mineral Status | - |
| Termination Finish (if Pb-free) | e3 - Sn matt plated |
| Termination Finish (if Pb-bearing) | Not available |
| How to Specify Pb-Free | All part numbers are Pb-free |
| ECCN | - |
| Packing | Tube |
|---|---|
| Quantity | 25 |
| Nett Weight Each | - |
| Reflow Process | Not applicable |
| MSL | Not applicable |
| Wave Process | Max 10s total contact, 260degC, 2 cycles |
| Shelf-life | None defined |
| Launch Date | - |
|---|---|
| Lifecycle | Obsolete |
| EOL Date / YTEOL Estimate | EOL in 2014 |
| Latest PCN Date | No PCNs |
| Alternative Part Number | - |
| Datasheet | TPD | |
| Application Note | TN001 Advice on Storage Conditions for Fixed Resistors | |
| Application Note | TN003 Methods for Coding Resistor Values in Part Numbers | |
| Application Note | TN005 EIA Standard Values for Resistors | |
| Application Note | TN007 Instant Access to Life Cycle and Obsolete Product Data Online |
