HCC242TX

High-Reliability Optoisolator

Lifecycle:

Active (Mature)

Brand:

Optek Technology

Distributor Inventory
Data Sheet
checkmark

Surface mountable on ceramic or printed circuit board

checkmark

Miniature package saves circuit board area

checkmark

Electrical performance similar to 4N22A and 4N24A

checkmark

Hermetically sealed

checkmark

Screened per MIL-PRF-19500 TX and TXV equivalent levels or per ESA 5000

Specifications

Applications Aerospace/defense applications
Package 4-Pin Ceramic LCC
High Reliability True
Screening Level Military (TX, TXV)
Hall Effect No
Photologic False
Lead Length Min / Max -
RoHs Compliance Y
Isolation Voltage 1kV
Sensor Type Phototransistor
CTR Min 100% @ 10mA
Operating Temperature -55°C ~ 125°C
Wavelength 890nm
Rise / Fall 20µs / 20µs (Max)ns
Prop Delay -
VCE Max 30 or 55V
VCC Range -
IF Typ/Max 40mA
CTR Max 1.5
Light Current IC(ON) Min -
Alternative Part Number -
