OPB962N51
Slotted Switch, N Package
Lifecycle:
Active (Mature)
Brand:
Optek Technology
Dual channel outputs for quadrature output
Open collector inverter outputs
0.010" (0.254mm) sensor apertures for high resolution
Snap mount
OPB950 5±.0.5 Volt Vcc, OPB951 4.75 to 16 Volt Vcc
Specifications
| Applications |
|
|---|---|
| Package Termination | Through-Hole |
| Slot Width | 0.125" |
| Slot Depth | 0.345" |
| Aperture Width Emitter / Sensor | 0.05 / 0.01" |
| High Reliability | No |
| Screening Level | - |
| Hall Effect | No |
| Photologic | Yes |
| Photo Interrupter Type | Slotted |
| Package | Switch, slotted LNPT |
| Lead Length Min | 0.425" |
| Lead Length Max | 0.425" |
| RoHs Compliance | Y |
| Output Type | Photologic |
|---|---|
| Supply Voltage | 4.5 ~ 16V |
| Operating Temperature | -40°C ~ 70°C |
| Wavelength | 890nm |
| VCE Max | - |
| VCC Range | 4.5 / 16V |
| Angle | - |
| IF Typ/Max | 20 / 50mA |
| Light Current IC(ON) Min | - |
| Light Current IC(ON) Max | - |
| ICCL/ICCH | 15 / 15mA |
| Alternative Part Number | - |
|---|
