Brand:
IRC
Series:
OARS
Lifecycle:
Mature
| Series | OARS |
|---|---|
| Application | Current sense |
| Mounting | SMD - solder |
| Package | SMD formed metal terminal |
| Technology | Metal element |
| Approval | AEC-Q200 |
| Example MPN | OARS3-R01JI or OARS3R010JLF |
| Termination Options | Pb-free |
| Product Brand | IRC |
| Power | 3W |
|---|---|
| Rated Ambient Temperature | 70°C |
| De-rate to 0W Ambient Temperature | 225°C |
| Max Ambient Temperature | 160°C |
| LEV | - |
| Resistance min | 2mΩ |
| Resistance max | 0.015Ω |
| Critical Resistance (where applying LEV dissipates Pr) | N/A: -Ω |
| Tolerance | 1% |
| TCR | 20ppm/°C |
| Isolation Voltage of Insulation | Uninsulated: 0V |
| RoHS Compliant (if Pb-free) | Yes (see below) |
|---|---|
| RoHS Exemption | None |
| China RoHS (if Pb-free) | Compliant |
| REACH Status (if Pb-free) | Reviewed to 223 SVHCs (see below) |
| CMRT Conflict Mineral Status | Rev 6.1 Next update May 2022 (see below) |
| EMRT Extended Mineral Status | Rev 2.2 Next update May 2022 (see below) |
| Termination Finish (if Pb-free) | e2 - SnAg (96S) |
| Termination Finish (if Pb-bearing) | Not available |
| How to Specify Pb-Free | All part numbers are Pb-free |
| ECCN | EAR99 |
| Packing | Plastic tape & reel |
|---|---|
| Quantity | 1900 |
| Nett Weight Each | - |
| Reflow Process | J-STD-020E |
| MSL | 1 |
| Wave Process | Not compatible |
| Shelf-life | None defined, but solderability test prior to use is recommended after two years from date of manufacture |
| Lifecycle | Mature |
|---|---|
| EOL Date / YTEOL Estimate | 5 years or more from May 2022 |
| Latest PCN Date | No PCNs |
| Alternative Product | - |
| Datasheet | OARS | |
| Application Note | Current Sense Resistors | |
| Application Note | TN001 Advice on Storage Conditions for Fixed Resistors | |
| Application Note | TN002 Instant Access to RoHS REACH Conflict Mineral and other Compliance Data Online | |
| Application Note | TN003 Methods for Coding Resistor Values in Part Numbers | |
| Application Note | TN005 EIA Standard Values for Resistors | |
| Application Note | TN007 Instant Access to Life Cycle and Obsolete Product Data Online | |
| Brochure | AECQ-200 Portfolio | |
| Brochure | Resistors Shorform Catalogue | |
| 3D Model | OARS1 R015 OARS3 R015 | |
| Compliance | Mexicali ISO 9001 | |
| Compliance | RoHS OARS | |
| Compliance | REACH Statement Dallas | |
| Compliance | CMRT Conflict Mineral Dallas | |
| Compliance | EMRT Extended Mineral Dallas | |
| Compliance | Proposition 65 Declaration Dallas | |
| Compliance | TSCA Statement Dallas | |
| Compliance | Tin Whisker Report |
