OPB700Z
Reflective Switch
Lifecycle:
Active (Mature)
Brand:
Optek Technology
Low profile to facilitate stacking
Low cost plastic housing
Choice of phototransistor or photodarlington output
#26 AWG lead wire in 4" (101 mm), or 18" (457 mm) lengths
Specifications
| Applications |
|
|---|---|
| Package Termination | 4" / 26 AWG Wire |
| High Reliability | No |
| Screening Level | - |
| Hall Effect | No |
| Photologic | No |
| Photo Detector Type | - |
| Material | - |
| Color | - |
| Lead Length Min | - |
| Lead Length Max | - |
| Receiver Type | - |
| Responsivity Min/Max/Typ | - |
| RoHs Compliance | Y |
| Output Type | Transistor |
|---|---|
| Test Distance | 0.200" (5.08mm) |
| Operating Temperature | -40°C ~ 100°C |
| Focused / Non-Focused | Focused |
| Endlooker / Sidelooker | Endlooker |
| Wavelength | 890nm |
| Rise Time Typ | - |
| Reverse Voltage | - |
| Peak Response Wavelength | - |
| Spectral Response Wavelength | - |
| Hysteresis Min (Gauss) | - |
| Hysteresis Max (Gauss) | - |
| Hysteresis Typ (Gauss) | - |
| VCE Max | 24V |
| VCC Range | - |
| IF Typ/Max | 40 / 100mA |
| Isolation Voltage Min | - |
| Light Current IC(ON) Min | 0.1mA |
| Light Current IC(ON) Max | - |
| Input/Output Power | - |
| ICCL/ICCH | - |
| Supply Voltage | 3V - 22V |
