Lifecycle:
Obsolete
Brand:
Welwyn
Series:
CC
| Series | CC |
|---|---|
| Application | Surge / pulse |
| Mounting | Through hole |
| Package | Axial |
| Technology | Carbon composition |
| Approval | None |
| Example MPN | CC1-6K8KB24 |
| Termination Options | Pb-free |
| Power | 1W |
|---|---|
| Rated Ambient Temperature | 25°C |
| De-rate to 0W Ambient Temperature | 125°C |
| Max Ambient Temperature | 125°C |
| LEV | - |
| Resistance min | 100Ω |
| Resistance max | 50kΩ |
| Critical Resistance (where applying LEV dissipates Pr) | N/A: -Ω |
| Best Tolerance | 10% |
| Best TCR | 1000ppm/°C |
| Isolation Voltage of Insulation | 500V |
| RoHS Compliant (if Pb-free) | Yes (see below) |
|---|---|
| RoHS Exemption | None |
| China RoHS (if Pb-free) | Compliant |
| REACH Status (if Pb-free) | See REACH statement pdf (below) |
| CMRT Conflict Mineral Status | See CMRT Excel file (below) |
| EMRT Extended Mineral Status | See EMRT Excel file (below) |
| Termination Finish (if Pb-free) | e3 - Sn hot dipped |
| Termination Finish (if Pb-bearing) | Not available |
| How to Specify Pb-Free | All part numbers are Pb-free |
| ECCN | EAR99 |
| Packing | Tape & ammo pack |
|---|---|
| Quantity | 2400 |
| Nett Weight Each | 1.1g |
| Reflow Process | Not applicable |
| MSL | Not applicable |
| Wave Process | Compatible, 260+-5 deg. C, 1 or 2 x 5+-1 seconds contact time |
| Shelf-life | None defined, but solderability test prior to use is recommended after two years from date of manufacture |
| Launch Date | Mar 2008 |
|---|---|
| Lifecycle | Obsolete |
| EOL Date / YTEOL Estimate | EOL in Jul 2022 |
| Latest PCN Date | 24 Jan 22 |
| Alternative Part Number | - |
| Datasheet | CC | |
| Application Note | TN001 Advice on Storage Conditions for Fixed Resistors | |
| Application Note | TN002 Instant Access to RoHS REACH Conflict Mineral and other Compliance Data Online | |
| Application Note | TN003 Methods for Coding Resistor Values in Part Numbers | |
| Application Note | TN004 Methods for Marking Values on Resistors | |
| Application Note | TN005 EIA Standard Values for Resistors | |
| Application Note | TN007 Instant Access to Life Cycle and Obsolete Product Data Online | |
| Compliance | Bedlington ISO 9001 | |
| Compliance | Bedlington Quality Policy | |
| Compliance | Bedlington ISO 14001 2015 | |
| Compliance | Bedlington Env Policy | |
| Compliance | Bedlington ISO 45001 2018 | |
| Compliance | Bedlington Health and Safety Policy | |
| Compliance | RoHS CC | |
| Compliance | REACH Statement Bedlington | |
| Compliance | CMRT Conflict Mineral Bedlington | |
| Compliance | EMRT Extended Mineral Bedlington | |
| Compliance | Proposition 65 Declaration Bedlington | |
| Compliance | TSCA Statement Bedlington | |
| Compliance | Tin Whisker Report | |
| Product Change Notification | PCNs for CC |
