Lifecycle:
Active (Mature)
Brand:
Welwyn
Series:
HTCR
| Series | HTCR |
|---|---|
| Application | High temperature |
| Mounting | SMD - solder |
| Package | Chip 2512 |
| Technology | Thick film |
| Approval | None |
| Example MPN | HTCR2512F-10KFT18 |
| Termination Options | Pb-free |
| Power | 1W |
|---|---|
| Rated Ambient Temperature | 70°C |
| De-rate to 0W Ambient Temperature | 200°C |
| Max Ambient Temperature | 200°C |
| LEV | 500V |
| Resistance min | 1Ω |
| Resistance max | 10MΩ |
| Critical Resistance (where applying LEV dissipates Pr) | 250kΩ |
| Best Tolerance | 1% |
| Best TCR | 100ppm/°C |
| Isolation Voltage of Insulation | Unspecified: ?V |
| RoHS Compliant (if Pb-free) | Yes (see below) |
|---|---|
| RoHS Exemption | 7(c)-I "Pb in glass" |
| China RoHS (if Pb-free) | Contains Pb. EFUP 50 Years |
| REACH Status (if Pb-free) | See REACH statement pdf (below) |
| CMRT Conflict Mineral Status | See CMRT Excel file (below) |
| EMRT Extended Mineral Status | No EMRT available |
| Termination Finish (if Pb-free) | e3 - Sn matt plated |
| Termination Finish (if Pb-bearing) | Not available |
| How to Specify Pb-Free | All part numbers are Pb-free |
| ECCN | EAR99 |
| Packing | Plastic tape & reel |
|---|---|
| Quantity | Up to 1800 |
| Nett Weight Each | - |
| Reflow Process | Not applicable |
| MSL | Not applicable |
| Wave Process | Not applicable |
| Shelf-life | None defined |
| Launch Date | Mar 2010 |
|---|---|
| Lifecycle | Active (Mature) |
| EOL Date / YTEOL Estimate | 5 years or more. (Reviewed May 24) |
| Latest PCN Date | No PCNs |
| Alternative Part Number | - |
