Lifecycle:
Active (Mature)
Brand:
Welwyn
Series:
WSHR
| Series | WSHR |
|---|---|
| Application | High power |
| Mounting | Heatsink |
| Package | Low profile power |
| Technology | Thick film |
| Approval | None |
| Example MPN | WSHR5-100RKTW |
| Termination Options | Non-solder |
| Power | 655W |
|---|---|
| Rated Ambient Temperature | - |
| De-rate to 0W Ambient Temperature | - |
| Max Ambient Temperature | 400°C |
| LEV | - |
| Resistance min | 22Ω |
| Resistance max | 150Ω |
| Critical Resistance (where applying LEV dissipates Pr) | N/A: -Ω |
| Best Tolerance | 10% |
| Best TCR | 600ppm/°C |
| Isolation Voltage of Insulation | 2.5kV |
| RoHS Compliant (if Pb-free) | Yes (see below) |
|---|---|
| RoHS Exemption | None |
| China RoHS (if Pb-free) | Compliant |
| REACH Status (if Pb-free) | See REACH statement pdf (below) |
| CMRT Conflict Mineral Status | See CMRT Excel file (below) |
| EMRT Extended Mineral Status | See EMRT Excel file (below) |
| Termination Finish (if Pb-free) | Non-solder |
| Termination Finish (if Pb-bearing) | Not available |
| How to Specify Pb-Free | All part numbers are Pb-free |
| ECCN | EAR99 |
| Packing | Bulk / box |
|---|---|
| Quantity | 40 |
| Nett Weight Each | - |
| Reflow Process | Not applicable |
| MSL | Not applicable |
| Wave Process | Not applicable |
| Shelf-life | None defined |
| Launch Date | Oct 2018 |
|---|---|
| Lifecycle | Active (Mature) |
| EOL Date / YTEOL Estimate | 5 years or more. (Reviewed May 25) |
| Latest PCN Date | 13 Oct 25 |
| Alternative Part Number | - |
